MC35 FCU Thermostat

Model Number: MC35-FCU Series

Power supply: 24VAC / 95-260vac, 50/60hz

Tuya Fan Coil Unit Thermostat

2 / 4 pipes HVAC system

3 speed or 0-10VDC fan control

On/Off relay or 0-10VDC valve control

Digit Input: Window / Occupy / Fire

Communicate: Modbus TCP /RTU / BACnet / MQTT / Lorawan


Collect
商品参数

Features:

Model NoMC35-FCU Series
Power Supply 95~230Vac / 24Vac, 50 / 60Hz
Purpose Of Control2 / 4 pipe
Relay Rating230VAC @5 Amp maximum per relay
Digit input
Window / Occupy / Fire
Fan 3 Speed / 0-10V Fan
ValveOn/Off valve / 0-10V Valve
Heat/CoolYES
Screen 320x480 pixels TFT, Capacitive touch screen
Key Card FunctionDry Contact
CommunicationModbus TCP / RTU
Temperature FormatC / F
ProgrammableNone / 5+2 / 7 Days / 24 Hours

Up to different 4- or 6-event

program

Setpoint Range5~35°C
Temperature Resolution 0.1°C
Operating Temperature / Humidity
Temp.: 1° c- 85° C
Humidity: 5~95%
ColorWhite / Black & Sliver / Black
Approval
CE / UKCA / ROHS Standard
InstallationFlush / Surface Mounting
Housing MaterialPC+ABS
IP GradeIP 20

PRODUCT MODEL

ModelSystemFanValveDigit InputModbusBACnet
2FA2 PIPE3 Speed3 WAYSWindows / Occupy / FireTCP / RTUYES
2FC2 PIPE3 Speed0-10VWindows / Occupy / FireTCP / RTUYES
2FGC2 PIPE0-10V0-10VWindows / Occupy / FireTCP / RTUYES
2FG2 PIPE0-10V2 WAYSWindows / Occupy / FireTCP / RTUYES
2FB12 PIPE220V FAN(0-100%)2 WAYS COOL / Electric heatingWindows / Occupy / FireTCP / RTUYES
4FDE4 PIPE3 Speed2 WAYSWindows / Occupy / FireTCP / RTUYES
4FD4 PIPE3 Speed0-10VWindows / Occupy / FireTCP / RTUYES
4FF4 PIPE3 Speed2 WAYSWindows / Occupy / FireTCP / RTUYES
4FI4 PIPE0-10V2 WAYSWindows / Occupy / FireTCP / RTUYES
