Home >> Product >>Electric Heating Thermostat >> Tuya Easy Operation Electric Heating Thermostat

Product Detail

Tuya Easy Operation Electric Heating Thermostat

Model Number:GD8209H-TUYA

Input voltage:AC220V, 50 / 60Hz Self power consumption: <1W

Temperature sensing element: NTC

Set range: 05℃ ~45℃ Display range: 0~99℃

Temperature control accuracy: ± 1℃ working environment: 5~45℃

Shell material: PC + ABS flame retardant protection grade: IP 30

Load current: 3A mounting hole distance: 60mm (standard)

Overall dimension: 86mmX86mmX 38mm (width X high X thick)

Collect

Product Description

Features:

Model No	X1 WIFI
Power Supply	95~230Vac / 24Vac, 50 / 60Hz
Purpose Of Control	Heating System
Relay Rating	230VAC @3 and 16 Amp maximum per relay
Digit input	No
Programmable	Manual / 5+2 program
Setpoint Range	5~45°C
Temperature Resolution	0.1°C
Operating Temperature / Humidity	Temp.: 1° c- 85° C Humidity: 5~95%
Color	White
Approval	CE / UKCA / ROHS Standard
Installation	Flush / Surface Mounting
Housing Material	PC+ABS
IP Grade	IP 20
