Home >> Product >>Water UFH Thermostat >> MC35 Water Underfloor Heating Thermostat
Product Detail

MC35 Water Underfloor Heating Thermostat

Model Number: MC35-HA-TY

Power supply: 85-260vac, 50/60hz

Tuya Electric Heating System

Multi Language: English, Deutsch, Czech, Espanol, French,

German, Italiano, Polish, Russian, Swedish, Croatian, Svenska etc

Multi Sensor: Inner / Remote / Floor Sensors

C/F Temperature Display

Set Temp. Range: 5~45℃ (software selectable)

Schdule: 5+2 Day, 7 Day And 24 Hour(Max 6 Timers)

Temperature Calibration



Collect
Product Description

Features:

Model NoMC35-HE
Power Supply95~230Vac / 24Vac, 50/60Hz
Purpose Of Control

Boiler/Valve/Underfloor

Water/electric heating system

Relay Rating

230VAC @5 Amp per relay; @16

Amp relay in electric heating model

Display

320x480 pixels TFT,

Capacitive touch screen

Temperature FormatC/F
Standby Consumption≤0.5 W
Temperature Range5~35°C
Temperature Set Range
5~45°C
SensorBulit In / Remote / Floor Sensor
Programmable

None / 5+2 / 7 Days / 24 Hours

Up to different 4- or 6-event

program

OutputVolt free switch /Switch Live
Sensor NTC10K

Temperature Resolution

0.1°C
Temperature ControlAccuracy: 0.5°C
Operating Temperature / Humidity
Temp.: 1° c- 85° C
Humidity: 5~95%
Color OptionWhite / Black & Sliver / Black
LanguageMulti Language ( 9 )
Approval
CE / UKCA / ROHS Standard
Dimensions (W/H/D)87 * 86 * 13.8 (mm)
InstallationFlush/Surface Mounting
Housing Material
PC+ABS
Enclosure RatingIP 20

PRODUCT MODEL

ModelSystem
Power Supply
 Heating RelayHot WaterExternal SensorWireless
HABoiler/Valve/Water UFH230VAC3AmpNoNoNo
HEElectric Heating230VAC16AmpNoNCT10K / 3950No
HWBoiler/Valve/Water UFH230VAC3AmpYESNoNo
